Entrar no modo de configuração

 configure

Sair do modo de configuração

 exit

Voltar ao modo operacional

 exit discard

Mostrar ajuda

 help

--- ## Sistema Mostrar versão do sistema

 show version

Mostrar configuração ativa

 show configuration

Mostrar estado do sistema

 show system status

Reiniciar roteador

 reboot

Desligar sistema

 poweroff

Salvar configuração

 commit
save

--- ## Configuração (base) Aplicar mudanças

 commit

Salvar permanentemente

 save

Descartar mudanças não aplicadas

 discard

--- ## Interfaces Mostrar interfaces

 show interfaces

Mostrar detalhes de interface

 show interfaces ethernet eth0

Configurar IP em interface

 set interfaces ethernet eth0 address 192.168.1.1/24

Habilitar interface

 set interfaces ethernet eth0 disable false

Desabilitar interface

 set interfaces ethernet eth0 disable true

Remover configuração de interface

 delete interfaces ethernet eth0 address

--- ## Rotas Mostrar tabela de rotas

 show ip route

Adicionar rota estática

 set protocols static route 0.0.0.0/0 next-hop 192.168.1.1

Remover rota estática

 delete protocols static route 0.0.0.0/0

--- ## BGP Configurar ASN local

 set protocols bgp 65001

Definir vizinho BGP

 set protocols bgp 65001 neighbor 10.0.0.1 remote-as 65002

Anunciar rede

 set protocols bgp 65001 network 192.168.1.0/24

Mostrar resumo BGP

 show ip bgp summary

Mostrar tabela BGP

 show ip bgp

Resetar sessão BGP

 clear ip bgp 10.0.0.1

--- ## OSPF Ativar OSPF

 set protocols ospf area 0 network 192.168.1.0/24

Mostrar vizinhos OSPF

 show ip ospf neighbor

Mostrar status OSPF

 show ip ospf

Remover OSPF

 delete protocols ospf

--- ## OSPFv3 (IPv6) Ativar OSPFv3

 set protocols ospfv3 area 0 interface eth0

Mostrar vizinhos IPv6 OSPF

 show ipv6 ospf neighbor

--- ## NAT Configurar NAT Masquerade

 set nat source rule 100 outbound-interface eth0
set nat source rule 100 source address 192.168.1.0/24
set nat source rule 100 translation address masquerade

Remover NAT

 delete nat source rule 100

--- ## Firewall Criar regra básica de firewall

 set firewall name WAN_IN default-action drop

Permitir SSH

 set firewall name WAN_IN rule 10 action accept
set firewall name WAN_IN rule 10 protocol tcp
set firewall name WAN_IN rule 10 destination port 22

Aplicar firewall na interface

 set interfaces ethernet eth0 firewall in name WAN_IN

--- ## DHCP Criar pool DHCP

 set service dhcp-server shared-network-name LAN subnet 192.168.1.0/24 range 0 start 192.168.1.100
set service dhcp-server shared-network-name LAN subnet 192.168.1.0/24 range 0 stop 192.168.1.200

Gateway DHCP

 set service dhcp-server shared-network-name LAN subnet 192.168.1.0/24 default-router 192.168.1.1

DNS DHCP

 set service dhcp-server shared-network-name LAN subnet 192.168.1.0/24 dns-server 8.8.8.8

--- ## Diagnóstico Ping

 ping 8.8.8.8

Traceroute

 traceroute 8.8.8.8

Ver ARP

 show arp

Ver conexões

 show ip connections

Ver logs

 show log

Monitor de interface

 monitor interface eth0

--- ## Debug Ativar debug BGP

 debug bgp

Ativar debug OSPF

 debug ospf

Desativar debug

 undebug all

--- ## VRF Criar VRF

 set vrf name CLIENTE

Mostrar VRFs

 show vrf

--- ## Limpeza / manutenção Limpar configuração de interface

 delete interfaces ethernet eth0

Resetar configuração parcial

 rollback 0
